VAX50080 RHF5 Turbocharger Core for Isuzu 4JJ1

The VAX50080 RHF5 turbocharger core is an aftermarket replacement CHRA assembly designed for Isuzu 4JJ1 (CIFN) engines, including the Hitachi ZX160LC-3 application. This unit features a balanced rotor assembly and machined compressor housing, serving as an aftermarket replacement component for maintenance and rebuild operations. Buyers should verify the specific turbo configuration and engine code before ordering to ensure correct fitment.

Key Specifications

• Part Number: VAX50080
• Product Type: Turbocharger Core (CHRA)
• Turbo Model: RHF5
• Gross Weight: 2 kg
• Application Clue: Isuzu 4JJ1 (CIFN) engine, Hitachi ZX160LC-3
• OEM References: No specific OEM reference numbers provided in input
• Image Availability: High-resolution studio shots available

This core assembly includes the compressor housing, turbine housing, and rotor shaft. The visible features include a machined silver compressor housing and a cast turbine housing with cooling fins. Buyers should inspect the physical unit for any damage to the oil slinger or backplate seals before installation.

Application & Compatibility

Source application path clues for buyer verification. These are source category/application paths, not confirmed fitment claims:

• HITACHI > HITACHI ZX160LC-3 > ISUZU 4JJ1 (CIFN)

This VAX50080 RHF5 core is listed for Isuzu 4JJ1 (CIFN) engines, specifically associated with the Hitachi ZX160LC-3 excavator application. Buyers should treat this as a replacement application clue rather than a confirmed fitment. Verify your specific machine’s turbo configuration, engine code, and production year against the VAX50080 part number before ordering. Since no OEM reference numbers are provided in the input, cross-check the physical unit’s markings and housing dimensions to ensure the RHF5 model matches your existing assembly. Technical fitment support is available to help confirm the correct core for your Isuzu 4JJ1 engine.

Technical Notes

The RHF5 turbo model is a fixed-geometry design, distinct from variable-geometry units. This core assembly includes the rotor shaft, compressor housing, and turbine housing. Visible features include a machined silver compressor face and a cast turbine housing with radial cooling fins. Two threaded ports are present on the turbine side for fluid connections. The central shaft features a threaded tip and nut for mounting. No specific material grades or performance specifications are visible in the provided images. Buyers should inspect the physical unit for oil slinger alignment and backplate seal integrity before installation. Verify the RHF5 model designation against your existing assembly to ensure the correct core is selected for the Isuzu 4JJ1 application.

B2B Supply

LeadTurbo supports B2B buyers, repair shops, and distributors with volume pricing for VAX50080 RHF5 cores. Worldwide shipping is available for this 2 kg unit. Technical fitment support is provided to help verify the Isuzu 4JJ1 (CIFN) application and Hitachi ZX160LC-3 reference before ordering. Inquire about bulk orders or specific packaging requirements for your fleet or rebuild operations.
